Gear Pump spec .pdf

The 400 magnet drive gear pumps are robust with excellent precision performance for high technology food and beverages industry. The pump is designed to work in high pressure and constant flow applications at limited space.

Material: SUS 304,  PEEK+GF, PTFE

Technical Specification

 Supply voltage:  24 VDC       No-load current :  ≤1.2A     No-load Flow:  1000  ml/min

Current @15bar :  ≤4A       15 bar Flow  ≥100 ml/min    Leakage pressure :  ＞20 bar

Water  temperature:  0 to 50℃      Connector :  G 1/8”

Life  50000 Cycle (1 min ON / 1 min OFF @ 8bar)

Characteristics:

Robust design, Food grade, High pressure, Long life, Simple control

Agressive fluids, Low maintenance
